1. Intuitive aesthetic interface - Color touch large screen design,the interface is simple and intuitive, so it's easy to learn and easy to use. Glass screen can be cleaned and disinfected by wiping.

2. Direct saline supply to reduce surgical infection rate -The use of a direct supply of sterilized and cooled saline in aseptic minimally invasive tooth extraction procedures can reduce the rate of surgical infection, fast wound healing and mild complications.

3. 1:1, 1:5, 1:4.2, different handpiece clinical application scenarios can be freely selected for more accurate and efficient dental treatments such as tooth preparation, extraction, decay, polishing, extraction and many other dental treatments.

4. Combined with a dental surgical dynamic system, it provides precise tooth preparation, better torque, speed control, better feel, smoother operation than turbines,more precise cutting edges and improves overall clinical outcomes.

5. The contra-angle handpiece with 45° head unites the advantages of both straight and contra-angle handpieces for the first time.

6. The visibility of the treated area is improved due to the 45° head. Also, it makes access to maxillary and mandibular teeth much simpler. This is particularly helpful in the surgical extraction of wisdom teeth, precise tooth separations and apical resections.

7. Brushless - maintenance free - no need for oil lubrication of bearings during service life. ISO E-type can be matched with conventional straight and contra-angle.

Technical parameters:

MAIN UNIT:

Size of main engine: L 300mm×W280mm×H128mm

Size of water tank: L200mm×W 100mm×H80mm

Input Voltage: 220VAC

Allowable voltage fluctuation: ±10%

Rated current: 0.1A-0.8A

Frequency: 50/60Hz

Power fuse: 2×250V-T1.6AH

Max.power consumption: 180VA

BRUSHLESS DIRECT-CURRENT MOTOR

Rated working voltage: DC32V

Operation mode: Forward / Reverse rotation

Standard Mode Speed Range: 100r/min~40,000 r/min

Max.torque of motor: Greater than lN.cm

Cooling gas flow: ≤40L/min

The Max.lux: ≥7000lx

Sterilization mode: 134C for not less than 3 minutes

Dimensions: Φ21.7mm×height70.5mm

GAS AND WATER SUPPLY

Cooling water flow at 100%: Above 50ml/min

Spray gas supply: Above 1.5L/min

Water quality and hardness range: Distilled/Purified water, Hardness<6.5mmol/L

Recommended cooling fluid: Distilled water / Purified Water

Max.allowable suspension load: ≤1.5Kg

Components:

Main engine x1

Brushless direct-current motor x1

Water tank x1

Pipe handle cover x1

Foot pedal x1

Motor bracket x1

Foot hook x1

Ceramic tube 1.6A 250V fuse x2

Power wire x1

Water bottle bracket x1

Sealing cover x1
